Eaton G4V-3-60 Design

Input:
Supply Voltage 20-32 VDC
Reverse Pol. Protection Yes
outputs with alternating function - PNP
Output:
Max output load <=400mA ; Duty Ratio 100%
Short Circuit Protection Yes
Hysteresis <=0.05mm
Electrical connector M12x1 4-Pole
Thermal shift <=±0.1mm
Plug connections:
Pin 1 + Supply
Pin 2 Normal Closed
Pin 3 0V
Pin 4 Normal Open
EMC Protection DIN EN 61000-6-1/2/3/4, Aug 2002
Humidity 0-95% rel. (nach DIN 40040)
Protection Class IP65 DIN 40050
Vibration 0-500Hz Max. 20g
Shock Max. 50g
• Factory setting ensures this condition under all combinations of manufacturing tolerance and of temperature drift (see “Temperature Limits”)

Input:
Supply Voltage 20-32 VDC
Reverse Pol. Protection Yes
outputs with alternating function - PNP
Output:
Max output load <=400mA ; Duty Ratio 100%
Short Circuit Protection Yes
Hysteresis <=0.05mm
Electrical connector M12x1 4-Pole
Thermal shift <=±0.1mm
Plug connections:
Pin 1 + Supply
Pin 2 Normal Closed
Pin 3 0V
Pin 4 Normal Open
EMC Protection DIN EN 61000-6-1/2/3/4, Aug 2002
Humidity 0-95% rel. (nach DIN 40040)
Protection Class IP65 DIN 40050
Vibration 0-500Hz Max. 20g
Shock Max. 50g
• Factory setting ensures this condition under all combinations of manufacturing tolerance and of temperature drift (see “Temperature Limits”)
